RIDGISTORMCheck Vortex Flow Control Chambers
Our RIDGISTORMCheck Vortex Flow Control Chambers are pre-fabricated structured wall chambers available in a range of diameters with an integral vortex flow control device. This allows precise control of site discharge rates and provides a flow attenuation solution recognised throughout the industry. Manufactured in a factory controlled environment allows for a strong high quality watertight structured walled chamber, eliminating wastage associate with in-situ construction. Being delivered as a one-piece modular solution reduces installation time and cost on-site, as well as minimising Health and Safety risks.
Site specific RIDGISTORMCheck Chambers engineered to suit a range of stormwater attenuation and infiltration systems providing a hydraulically efficient means of flow regulation.
Features & Benefits
- Self-activating vortex flow controller which controls forward flow of water
- No moving parts - virtually maintenance free
- No power supply required
- Manufactured with an integral sump for silt catchment and removal
- Available as non-bypass or manual bypass with built in overflow, if required
- WRc approved
- Manufactured to adoptable standards
- Tailor-made, fully-welded, watertight structured wall chambers to suit project-specific requirements
- Self-activating vortex flow controller which controls forward flow of water
- No moving parts - virtually maintenance free
- No power supply required
- Manufactured with an integral sump for silt catchment and removal
- Available as non-bypass or manual bypass with built in overflow, if required
- WRc approved
- Manufactured to adoptable standards
- Tailor-made, fully-welded, watertight structured wall chambers to suit project-specific requirements
- Multiple inlet and outlet options, supplied with integral sockets as standard allowing quick and seamless connection to pipeline
- Depths can be tailored to suit project requirements
- Lockable steel covers available
- Integral benching
- Step rungs to BS EN 13101 and ladders to BS EN 14376
- Optional riser section
- Riser location ring
- Integral lifting points available on request to improve Health and Safety during handling and installation
